CartManager XD Field Technician Guide Page 5
CartManager XD Features and Controls
This table provides a description of each of the parts shown in the preceding diagrams.
DESCRIPTION OF THE FUNCTION
Receives signals from the remote control. Also outputs the (unlock)
signal for the shopping cart wheels.
The anti-static chain prevents damage to the CartManager electrical
components by dissipating static electricity buildup. DO NOT DETACH
Controls and monitors the battery charging process.
Battery Discharge Indicator
Shows the percentage of charge left in the batteries. You should
recharge the batteries any time the charge falls below 50%. The unit can
also be plugged in between runs to keep the batteries “topped off” at full
charge. Also displays error codes on HD,XD and XDWi models, by
flashing a set of lights that can be corresponded with the (Trucharge
Fault Indicator LED (XDW
Displays error codes, by blinking a series of lights. This is used to
diagnose problems with the CartManager XDW by corresponding with
the (LED Error Codes sheet).
Brake Release (Brake Rod)
Engages/disengages the manual brake. When the lever is pulled out, the
brake is disengaged and CartManager can be manually pushed without
using the drive throttles. When the brake lever is pushed in, the brake is
disengaged while the unit being driven using the drive motor and
engaged when the unit is stopped. The brake release lever must be
pushed in to use CartManager with the drive throttles or the remote
Foam filled, heavy tread tires and wheels connected to the transaxles
hubs.
The hood covers and protects the batteries and components in the
battery compartment. When opening and closing use the inset handles
on either side of the hood. Do not grip the hood by the front edge; you
Holds the strobe light and strobe light cage. Swings up for operation and
down for getting under low overhangs or doors.
Allows the unit to swivel and turn completely around within its own
length. This wheel is not connected to the drive motor.
Covers and protects the controller and other electronic components.
Convenient storage for the remote control when it is not in use.
Allows the receiver to associate (with) the remote.
Supplies A/C current to the charger and the charger inter-lock relay.
Holds the coil cord in a stationary position.
Shuts down the CartManager when the unit is plugged in for charging.
Does not allow the user to drive the CartManager while it is plugged in,
causing damage to the coil cord.
Allows you to sound the horn when pressed.
Regulates the speed of the CartManager in response of the throttle
applied.
The function of the motor brake is to not allow the machine to roll when
stopped.
Drives the axles so that the unit will move forward and backwards .
Has inputs and outputs for both manual and remote operations.
Protects the entire electronics in case of a major amp draw or shortage.
Fuse Block Fuses 2, 5,10 Amp
To protect individual circuits from shortages or high amp draws.
