Battery installation
電池固定
GAUI
TAI SHIH HOBBY CORPORATION
Battery installation
電池固定
M3x10......................x1
將電池推至定位後，確認電池隔板是否嵌入電池掛件內，
再鎖入電池固定器。
電池掛件
電池固定器
將固定好的電池隔板插入機身的溝槽內，注意電池隔板方向是否正確(如圖示)。
Slide assembled Battery/battery tray into Slider Seat (refer to correct
orientation of tray as depicted below).
Push Battery tray into position.
Battery Slider Seat (Center)
Battery tray locking screws
