GAUI X4 - Canopy and Main Blades Installation

21
GAUI
TAI SHIH HOBBY CORPORATION
Canopy installation
艙罩組裝
GAUI
TAI SHIH HOBBY CORPORATION
Main Blades installation
主槳組裝
將艙罩扣至定位後，插入R型插銷固定艙罩。
M3x22
M3x22......................x2
N3x5.5L...................x2
W3x6x0.5
N3x5.5L
Install canopy into position, insert R shaped
pin to lock it into place.
22
