36
11
30
10
14
12
The Top Tether can be extended, if required, by pressing
the adjustment button (10).
Detach the Top Tether (11) from the designated storage
compartment (30). Guide the Top Tether straight across
the vehicle seat and anchor it using the snap pin of the
anchor point (12) of your vehicle.
!
WARNING! Pass the Top Tether between the top
of the vehicle seat backrest and the headrest.
Never pass the Top Tether above the vehicle seat
headrest.
!
WARNING! The Top Tether may only be fastened
to a marked attachment point. In case of uncer-
tainty, please comply with the manual of your
vehicle.
!
WARNING! The Top Tether must not be twisted.
Tighten the Top Tether by pulling the belt until the safe-
ty indicator (14) of the Top Tether becomes GREEN.
Roll up belt in excess and fasten it with the provided
elastic band.
Activate the side protector which is located on the door
side (see chapter: ”ADJUSTING THE SIDE PROTECTORS“).
To Next Page
