GBA ST1C - USB Download Error Codes

GBA Global Bill Acceptors GBA ST1C Operation Manual
Page 15 of 30 Astrosys International Ltd
GBA ST1C Operations manual V1_4
4.3.4 USB Download Error codes displayed by the diagnostic LED:
Status / Fault Flash 1 Flash 2 Flash 3 Flash 4
Success Orange Green Green Green
On board Faults
Fault with validator USB interface Orange Red Red Orange
Bus Error (Slave and Host pins high) Orange Red Red Red
USB Download Disabled Orange Red Red Green
Device Faults
USB Device not recognised Orange Orange Red Green
Cannot read MST Boot Sector Orange Orange Red Orange
Error reading MST Orange Orange Red Red
File faults
Too many dataset files found Orange Orange Orange Green
Error in dataset file Orange Orange Orange Orange
Too many configuration files found Orange Orange Orange Red
Error in configuration file Orange Orange Green Green
Too many firmware files found Orange Orange Green Orange
Error in firmware file Orange Orange Green Red
Firmware does not support this
dataset Orange Red Orange Orange
