2.2 Product Architecture
2.2 Image of product assembly
The GBA ST1C product consists of Main Chassis (1) which supports the Top Sensor Assembly (not
shown) and Bottom Sensor Assembly (2). Inter-changeable accessories are:
(3) Bill Cassette (300 Bills storage)
(4) Faceplate / External Note Guides
- For Faceplate/Note Guide Options refer to section 2.2.4 Note Guide & Faceplate
3. Bill Cassette
1. Main Chassis
4. Faceplate /
Note Guide
2. Bottom
Sensor
Assembly
