GBA ST1C - Illuminated Note Guide Patterns

GBA Global Bill Acceptors GBA ST1C Operation Manual
Page 17 of 30 Astrosys International Ltd
GBA ST1C Operations manual V1_4
How to handle a note that is found in the validator at power up: If the ST1C validator detects that
there is a note in the note path when it powers up, by default it will return the note to the user.
However, for some applications this behaviour is undesirable as the user is awarded a credit
before a note is stacked. The validator can be configured to stack the note instead.
Depending on the interface selected, the validator will give one of the following messages:
Interface Message to host
Pulse and Parallel No message
BSCP (RS232) Note type zero stacked (zero = unknown denomination)
MDB Note rejected
ccTalk Unknown Bill Type Stacked (event code 0,21)
SSP Unknown Note Stacked At Reset (event code 0xE2)
JVI/VCCS No message
4.5 Illuminated Note Guide Patterns
The illuminated note guide can be configured to flash different patterns according to the validator
state:
ST1C State Pattern
Out of Service - fault Note Guide off
Not accepting notes at the request of the
host controller.
Note Guide off
In service, waiting for a note Note Guide on
In service, handling a note Flashes the top and bottom alternately
