GBA ST1C - Illuminated Note Guide Status; Note Reject Status LED Codes

GBA Global Bill Acceptors GBA ST1C Operation Manual
Page 26 of 30 Astrosys International Ltd
GBA ST1C Operations manual V1_4
8.1.2 Illuminated Note guide:
The GBA ST1C has a blue illuminated note guide. If the ST1C is out of service, then this will be
switched off.
8.1.3 Status LED – Note Reject Codes:
If a note is rejected then a flash code is given when the note is removed (the LED will flash red or
orange a number of times):
Cause of Note Rejection Number of flashes
Unrecognised note 1 Red
Optical Anti String Gate was triggered 2 Red
Mechanical Anti String Gate did not close successfully 2 Orange
Note Inhibited in the configuration 3 Red
Note Inhibited by the Host 3 Orange
Note slipped or was held by the user as it was scanned 4 red
Front of the note hit the Mechanical Gate 4 Orange
Note inserted skewed 5 Red
Note is too long or two notes inserted 6 Red
