GCE OC-E100 - Specifications and Disposal; Technical Specifications; Disposal Guidelines

10/167
EN
The float in the flow meter
does not move up or down
when adjusting the flow
control dial.
The flow control dial is not
open.
Turn the flow control dial slowly
and carefully.
The flow control dial is
faulty.
Contact your home care provider.
There is water in the can-
nula.
There has been a change
in temperature;
OR
The device is too clo-
se to a wall, curtains or
furniture.
Dry the inside of the humidifier
cover.
Do not use hot water in the humi-
difier bottle.
Do not overfill the humidifier
bottle.
Keep the oxygen concentrator
and cannula in the same room at
the same temperature.
If using an extension hose with
your oxygen concentrator, speak
to your home care provider ab-
out fitting a water trap to collect
excess moisture.
5. SPECIFICATIONS
Technical Specifications
ModelModel OC-E80OC-E80 OC-E100OC-E100
Power consumption (W) 650
750W 6A (North America)
650
750W 6A (North America)
Rating current (A) 2.25 2.25
Electrical requirements 220V (+/- 10%) 50HZ (+/-10%)
220V (+/- 10%) 60HZ (+/-10%)
115V (+/- 10%) 60HZ (+/-10%)
220V (+/- 10%) 50HZ (+/-10%)
220V (+/- 10%) 60HZ (+/-10%)
115V (+/- 10%) 60HZ (+/-10%)
Flow rate (L/min) 1 to 8 1 to 10
Purity 93±3% 90±3%
Outlet pressure (mpa) 0.05±0.005 0.05±0.005
Dimensions 381 mm x 347 mm x 689 mm 381 mm x 347 mm x 689 mm
Net weight 27 kg 27 kg
Sound level 50 dBA or less 50 dBA or less
Equipment class and
type
Class IIa Class IIa
EMC compliance IEC 60601-1-2 IEC 60601-1-2
Features Standard: LCD display; oxygen concentration indicator; tempe-
rature alarm; high/low pressure alarm; low oxygen concentra-
tion alarm; power failure alarm; timed setting; intelligent fault
diagnosis; maintenance reminder.
Additional: Positive pressure outlet
Disposal
Dispose of this device in accordance with local regulations.
