GCS CYSCAN - Appendix 4 - Cyscan RS485 Data Converter Mounting Template

35CyScan Positioning System • Installation and Maintenance Guide r1.1
GC S
GC S
Appendix 4 - CyScan RS485 Data Converter Mounting Template
107
157
Height 125
Width 175
Outline of RS485 Housing
4 Holes M4
Allow cable clearance as shown
Allow housing depth of 130mm from mounting plate
Remove the Converter lid to access the fixing holes. Mount
the unit close to the CyScan Console laptop computer.
TOP
BOTTOM
