User’s Manual
3
Part name Part number Description Qty.
Carrying Case
GHDM – 011200
(Option Item)
Carrying Case for keeping or moving
the VCI module, VMI module, and
Cables,
1
Assy.-VCI module
GHDM - 210000
VCI module for scan-tool functions and
ECU upgrade, and Flight Recording.
1
Assy.-Trigger module
GHDM - 220000
The trigger module is used to manage
the data during the flight record mode
in the VCI module, it can also be used
as a DC power supply for the VCI
module.
Use a 250V, 2A Fuse with this
assembly.
1
Cable-Mini USB
GHDM – 360000
Cable for communication between VCI
and Information Terminal.
Length 3.5m.
1
Module: A-01-001 (p.02)
