GDS VCI - Page 6

User’s Manual
6
Part name
Part number Description Qty.
Adapter (self-test)
GHDM – 24D000
This self-test adapter is used for self-
diagnosis functions that are described
in a separate chapter. Do not use this
adapter except for its specified
purposes. For more information about
self-diagnosis, see chapter A-01-006
Self-test adapter.
1
6p--DC jack
GHDM – 250000
Use this adapter when supplying
power to the VCI main module without
the vehicle’s battery.
1
AC-DC Power adapter
GHDM – 260000
Adapter for supplying power to the VCI
main module from AC power
1
AC power cable
GHDM - 273000
Cable for AC/DC adapter
The socket plug for AC power cable
can be different depends on each
area. Please take this socket plug in
your local site.
1
Module: A-01-001 (p.05)
