1-8 489 Generator Management Relay
GE Power Management
1.2 SPECIFICATIONS 1 INTRODUCTION
1
CASE
Drawout: Fully drawout (Automatic CT shorts)
Seal: Seal provision
Door: Dust ti
ht door
Mountin
: Panel or 19" rack mount
IP Class: IP20-X
PRODUCTION TESTS
Thermal Cyclin
: Operational test at ambient, reducin
to
–40°C and then increasin
to 60°C
Dielectric Stren
th: 2.0 kV for 1 minute from relays, CTs,
VTs, power supply to Safety Ground
DO NOT CONNECT FILTER GROUND TO
SAFETY GROUND DURING TEST!
FUSE
Current Ratin
:3.15A
Type: 5 × 20 mm Slo-Blo Littelfuse, Hi
h
Breakin
Capacity
Model#: 215.315
An external fuse must be used if supply voltage
exceeds 250V
TYPE TESTS
Dielectric Stren
th: Per IEC 255-5 and ANSI/IEEE C37.90.
2.0 kV for 1 minute from relays, CTs,
VTs, power supply to Safety Ground
DO NOT CONNECT FILTER GROUND TO SAFETY
GROUND DURING TEST
Insulation Resistance: IEC255-5 500 V DC, from relays, CTs,
VTs, power supply to Safety Ground
DO NOT CONNECT FILTER GROUND TO
SAFETY GROUND DURING TEST
Transients: ANSI C37.90.1 oscillatory (2.5 kV/
1 MHz); ANSI C37.90.1 Fast Rise (5 kV/
10 ns); Ontario Hydro A-28M-82;
IEC255-4 Impulse/Hi
h Frequency Dis-
turbance Class III Level
Impulse Test: IEC 255-5 0.5 Joule 5 kV
RFI: 50 MHz / 15 W Transmitter
EMI: C37.90.2 Electroma
netic Interference
at 150 MHz and 450 MHz, 10V/m
Static: IEC 801-2 Static Dischar
e
Humidity: 90% non-condensin
Temperature: –40°C to +60°C ambient
Environment: IEC 68-2-38 Temperature/Humidity cycle
Vibration: Sinusoidal Vibration 8.0
for 72 hrs.
PACKAGING
Shippin
Box: 12” × 11” × 10” (W × H × D)
30.5cm × 27.9cm × 25.4cm
Shippin
Wei
ht: 17 lbs Max / 7.7 k
CERTIFICATION
ISO: Manufactured under an ISO9001 re
is-
tered system.
UL: UL
CSA: CSA
CE: Conforms to IEC 947-1, IEC 1010-1
WARNING
WARNING
