6.3 MEMORY MAP 6 COMMUNICATIONS
6
04AC RTD #11 TEMPERATURE –52 to 251 1 °C F4 –52
04AD RTD #12 TEMPERATURE –52 to 251 1 °C F4 –52
04C0 HOTTEST STATOR RTD TEMPERATURE –52 to 250 1 °F F4 –52
04C1 RTD #1 TEMPERATURE –52 to 251 1 °F F4 –52
04C2 RTD #2 TEMPERATURE –52 to 251 1 °F F4 –52
04C3 RTD #3 TEMPERATURE –52 to 251 1 °F F4 –52
04C4 RTD #4 TEMPERATURE –52 to 251 1 °F F4 –52
04C5 RTD #5 TEMPERATURE –52 to 251 1 °F F4 –52
04C6 RTD #6 TEMPERATURE –52 to 251 1 °F F4 –52
04C7 RTD #7 TEMPERATURE –52 to 251 1 °F F4 –52
04C8 RTD #8 TEMPERATURE –52 to 251 1 °F F4 –52
04C9 RTD #9 TEMPERATURE –52 to 251 1 °F F4 –52
04CA RTD #10 TEMPERATURE –52 to 251 1 °F F4 –52
04CB RTD #11 TEMPERATURE –52 to 251 1 °F F4 –52
04CC RTD #12 TEMPERATURE –52 to 251 1 °F F4 –52
METERING DATA / DEMAND METERING
04E0 CURRENT DEMAND 0 to 1000000 1 Amps F12 0
04E2 MW DEMAND 0 to 2000000 1 MW F13 0
04E4 Mvar DEMAND 0 to 2000000 1 Mvar F13 0
04E6 MVA DEMAND 0 to 2000000 1 MVA F13 0
04E8 PEAK CURRENT DEMAND 0 to 1000000 1 Amps F12 0
04EA PEAK MW DEMAND 0 to 2000000 1 MW F13 0
04EC PEAK Mvar DEMAND 0 to 2000000 1 Mvar F13 0
04EE PEAK MVA DEMAND 0 to 2000000 1 MVA F13 0
METERING DATA / ANALOG INPUTS
0500 ANALOG INPUT 1 –50000 to 50000 1 Units F12 0
0502 ANALOG INPUT 2 –50000 to 50000 1 Units F12 0
0504 ANALOG INPUT 3 –50000 to 50000 1 Units F12 0
0506 ANALOG INPUT 4 –50000 to 50000 1 Units F12 0
METERING DATA / SPEED
0520 TACHOMETER 0 to 7200 1 RPM F1 0
LEARNED DATA / PARAMETER AVERAGES
0600 AVERAGE GENERATOR LOAD 0 to 2000 1 %FLA F1 0
0601 AVERAGE NEG. SEQ. CURRENT 0 to 2000 1 %FLA F1 0
0602 AVERAGE PHASE-PHASE VOLTAGE 0 to 50000 1 V F1 0
0603 RESERVED – – – – –
0604 RESERVED – – – – –
LEARNED DATA / RTD MAXIMUMS
0620 RTD #1 MAX. TEMP. –52 to 251 1 °C F4 –52
0621 RTD #2 MAX. TEMP. –52 to 251 1 °C F4 –52
0622 RTD #3 MAX. TEMP. –52 to 251 1 °C F4 –52
0623 RTD #4 MAX. TEMP. –52 to 251 1 °C F4 –52
0624 RTD #5 MAX. TEMP. –52 to 251 1 °C F4 –52
0625 RTD #6 MAX. TEMP. –52 to 251 1 °C F4 –52
0626 RTD #7 MAX. TEMP. –52 to 251 1 °C F4 –52
0627 RTD #8 MAX. TEMP. –52 to 251 1 °C F4 –52
0628 RTD #9 MAX. TEMP. –52 to 251 1 °C F4 –52
0629 RTD #10 MAX. TEMP. –52 to 251 1 °C F4 –52
062A RTD #11 MAX. TEMP. –52 to 251 1 °C F4 –52
062B RTD #12 MAX. TEMP. –52 to 251 1 °C F4 –52
0640 RTD #1 MAX. TEMP. –52 to 251 1 °F F4 –52
0641 RTD #2 MAX. TEMP. –52 to 251 1 °F F4 –52
0642 RTD #3 MAX. TEMP. –52 to 251 1 °F F4 –52
Table 6–1: 489 MEMORY MAP (Sheet 6 of 29)
ADDR NAME RANGE STEP UNITS FORMAT DEFAULT
1, 2, 3 See Table footnotes on page 6–39
