489 Generator Management Relay 6-35
6 COMMUNICATIONS 6.3 MEMORY MAP
6
2B0E AVERAGED GEN. LOAD MIN 0 to 2000 1
×
FLA F3 0
2B0F AVERAGED GEN. LOAD MAX 0 to 2000 1
×
FLA F3 125
2B10 HOTTEST STATOR RTD MIN –50 to 250 1 °C F4 0
2B11 HOTTEST STATOR RTD MAX –50 to 250 1 °C F4 200
2B12 HOTTEST BEARING RTD MIN –50 to 250 1 °C F4 0
2B13 HOTTEST BEARING RTD MAX –50 to 250 1 °C F4 200
2B14 AMBIENT RTD MIN –50 to 250 1 °C F4 0
2B15 AMBIENT RTD MAX –50 to 250 1 °C F4 70
2B16 RTD #1 MIN –50 to 250 1 °C F4 0
2B17 RTD #1 MAX –50 to 250 1 °C F4 200
2B18 RTD #2 MIN –50 to 250 1 °C F4 0
2B19 RTD #2 MAX –50 to 250 1 °C F4 200
2B1A RTD #3 MIN –50 to 250 1 °C F4 0
2B1B RTD #3 MAX –50 to 250 1 °C F4 200
2B1C RTD #4 MIN –50 to 250 1 °C F4 0
2B1D RTD #4 MAX –50 to 250 1 °C F4 200
2B1E RTD #5 MIN –50 to 250 1 °C F4 0
2B1F RTD #5 MAX –50 to 250 1 °C F4 200
2B20 RTD #6 MIN –50 to 250 1 °C F4 0
2B21 RTD #6 MAX –50 to 250 1 °C F4 200
2B22 RTD #7 MIN –50 to 250 1 °C F4 0
2B23 RTD #7 MAX –50 to 250 1 °C F4 200
2B24 RTD #8 MIN –50 to 250 1 °C F4 0
2B25 RTD #8 MAX –50 to 250 1 °C F4 200
2B26 RTD #9 MIN –50 to 250 1 °C F4 0
2B27 RTD #9 MAX –50 to 250 1 °C F4 200
2B28 RTD #10 MIN –50 to 250 1 °C F4 0
2B29 RTD #10 MAX –50 to 250 1 °C F4 200
2B2A RTD #11 MIN –50 to 250 1 °C F4 0
2B2B RTD #11 MAX –50 to 250 1 °C F4 200
2B2C RTD #12 MIN –50 to 250 1 °C F4 0
2B2D RTD #12 MAX –50 to 250 1 °C F4 200
2B2E AB VOLTAGE MIN 0 to 150 1
×
Rated F3 0
2B2F AB VOLTAGE MAX 0 to 150 1
×
Rated F3 125
2B30 BC VOLTAGE MIN 0 to 150 1
×
Rated F3 0
2B31 BC VOLTAGE MAX 0 to 150 1
×
Rated F3 125
2B32 CA VOLTAGE MIN 0 to 150 1
×
Rated F3 0
2B33 CA VOLTAGE MAX 0 to 150 1
×
Rated F3 125
2B34 AVERAGE VOLTAGE MIN 0 to 150 1
×
Rated F3 0
2B35 AVERAGE VOLTAGE MAX 0 to 150 1
×
Rated F3 125
2B36 VOLTS/HERTZ MIN 0 to 200 1
×
Rated F3 0
2B37 VOLTS/HERTZ MAX 0 to 200 1
×
Rated F3 150
2B38 FREQUENCY MIN 0 to 9000 1 Hz F3 5900
2B39 FREQUENCY MAX 0 to 9000 1 Hz F3 6100
2B3C POWER FACTOR MIN –99 to 100 1 – F6 80
2B3D POWER FACTOR MAX –99 to 100 1 – F6 –80
2B3E REACTIVE POWER MIN –200 to 200 1
×
Rated F6 0
2B3F REACTIVE POWER MAX –200 to 200 1
×
Rated F6 125
2B40 REAL POWER (MW) MIN –200 to 200 1
×
Rated F6 0
2B41 REAL POWER (MW) MAX –200 to 200 1
×
Rated F6 125
2B42 APPARENT POWER MIN 0 to 200 1
×
Rated F3 0
2B43 APPARENT POWER MAX 0 to 200 1
×
Rated F3 125
2B44 ANALOG INPUT 1 MIN –50000 to 50000 1 Units F12 0
Table 6–1: 489 MEMORY MAP (Sheet 25 of 29)
ADDR NAME RANGE STEP UNITS FORMAT DEFAULT
1, 2, 3 See Table footnotes on page 6–39
