6-34 489 Generator Management Relay
GE Power Management
6.3 MEMORY MAP 6 COMMUNICATIONS
6
2A63 CURRENT DEMAND LIMIT 10 to 2000 1
×
FLA F14 125
2A65 CURRENT DEMAND ALARM EVENTS 0 to 1 1 A F105 0
MONITORING / MW DEMAND
2A70 MW DEMAND PERIOD 5 to 90 1 min F1 15
2A71 MW DEMAND ALARM 0 to 2 1 – F115 0
2A72 ASSIGN ALARM RELAYS (2-5) 1 to 4 1 – F50 16
2A73 MW DEMAND LIMIT 10 to 200 1
×
Rated F14 125
2A75 MW DEMAND ALARM EVENTS 0 to 1 1 – F105 0
MONITORING / Mvar DEMAND
2A80 Mar DEMAND PERIOD 5 to 90 1 min F1 15
2A81 Mar DEMAND ALARM 0 to 2 1 – F115 0
2A82 ASSIGN ALARM RELAYS (2-5) 1 to 4 1 – F50 16
2A83 Mar DEMAND LIMIT 10 to 200 1
×
Rated F14 125
2A85 Mar DEMAND ALARM EVENTS 0 to 1 1 – F105 0
MONITORING / MVA DEMAND
2A90 MVA DEMAND PERIOD 5 to 90 1 min F1 15
2A91 MVA DEMAND ALARM 0 to 2 1 – F115 0
2A92 ASSIGN ALARM RELAYS (2-5) 1 to 4 1 – F50 16
2A93 MVA DEMAND LIMIT 10 to 200 1
×
Rated F14 125
2A95 MVA DEMAND ALARM EVENTS 0 to 1 1 – F105 0
MONITORING / PULSE OUTPUT
2AB0 POS. kWh PULSE OUT RELAYS (2-5) 1 to 4 1 – F50 0
2AB1 POS. kWh PULSE OUT INTERVAL 1 to 50000 1 – F1 10
2AB2 POS. kvarh PULSE OUT RELAYS (2-5) 1 to 4 1 – F50 0
2AB3 POS. kvarh PULSE OUT INTERVAL 1 to 50000 1 – F1 10
2AB4 NEG. kvarh PULSE OUT RELAYS (2-5) 1 to 4 1 – F50 0
2AB5 NEG. kvarh PULSE OUT INTERVAL 1 to 50000 1 – F1 10
2AB6 PULSE WIDTH 200 to 1000 1 – F1 200
MONITORING / RUNNING HOUR SETUP
2AC0 INITIAL GEN. RUNNING HOUR 0 to 999999 1 h F12 0
2AC2 GEN. RUNNING HOUR ALARM 0 to 2 1 – F115 0
2AC3 ASSIGN ALARM RELAYS (2-5) 1 to 4 1 – F50 16
2AC4 GEN. RUNNING HOUR LIMIT 1 to 1000000 1 h F12 1000
2AC6 RESERVED
ANALOG I/O / ANALOG OUTPUT 1
2B00 ANALOG OUTPUT 1 0 to 42 1 – F127 0
ANALOG I/O / ANALOG OUTPUT 2
2B01 ANALOG OUTPUT 2 0 to 42 1 – F127 0
ANALOG I/O / ANALOG OUTPUT 3
2B02 ANALOG OUTPUT 3 0 to 42 1 – F127 0
ANALOG I/O / ANALOG OUTPUT 4
2B03 ANALOG OUTPUT 4 0 to 42 1 – F127 0
ANALOG I/O / ANALOG OUTPUTS
2B04 IA OUTPUT CURRENT MIN 0 to 2000 1
×
FLA F3 0
2B05 IA OUTPUT CURRENT MAX 0 to 2000 1
×
FLA F3 125
2B06 IB OUTPUT CURRENT MIN 0 to 2000 1
×
FLA F3 0
2B07 IB OUTPUT CURRENT MAX 0 to 2000 1
×
FLA F3 125
2B08 IC OUTPUT CURRENT MIN 0 to 2000 1
×
FLA F3 0
2B09 IC OUTPUT CURRENT MAX 0 to 2000 1
×
FLA F3 125
2B0A AVG OUTPUT CURRENT MIN 0 to 2000 1
×
FLA F3 0
2B0B AVG OUTPUT CURRENT MAX 0 to 2000 1
×
FLA F3 125
2B0C NEG. SEQ. CURRENT MIN 0 to 2000 1 %FLA F1 0
2B0D NEG. SEQ. CURRENT MAX 0 to 2000 1 %FLA F1 100
Table 6–1: 489 MEMORY MAP (Sheet 24 of 29)
ADDR NAME RANGE STEP UNITS FORMAT DEFAULT
1, 2, 3 See Table footnotes on page 6–39
