GE 60-806-95R-16Z - Security Concord Express System Control Panel User Manual

Programming the Panel 18
Touchpad Button Programming Functions
In program mode, the touchpad buttons let you navigate to all installer programming menus for
configuring the system. Table 3 describes the touchpad button functions in program mode.
Moving Through Program Mode Tiers and Menus
There are two basic tiers of programming menus. Tier 1 menus are accessible immediately after
entering program mode (see Figure 21).
Figure 21. Tier 1 Programming Menus
Arrows pointing right represent pressing B, arrows pointing left represent pressing A.
The arrow below the
SYSTEM PROGRAMMING menu represents pressing ƒ to move to tier 2 pro-
gramming menus.
Only when
SYSTEM PROGRAMMING is displayed can you advance to tier 2 menus (see Figure 22).
Figure 22. Tier 2 Programming Menus
Again, arrows pointing right represent pressing B, arrows pointing left represent pressing A.
Arrows below each menu represent pressing
ƒ (or ‚) to advance to (or back up from) those set-
tings that pertain to that menu. Only when a specific menu is displayed can you advance to those
settings. For example, pressing
ƒ from the SENSORS menu gives you access to learning sensors,
programming sensor text, deleting sensors, and viewing sensor programming.
Table 3: Alphanumeric Touchpad Buttons
Button Programming Function
ƒ
Selects menu item or data entry.
‚ Deselects menu item or data entry (if pressed before ƒ).
A & B
Scroll through available options at the current menu tier. Also scroll through
sensor text options during sensor text programming.
C
Enters pauses when programming phone numbers.
D
Deletes certain programmed settings.
0 thru 9
Enter numeric values wherever needed.
1 & 2
Select off (1) or on (2) wherever needed.
1 thru 6
Press and hold to enter alphabetical characters A thru F for account numbers.
7 or 9
Press and hold to enter * (7) or # (9) for phone numbers.
#
A
B
A
B
A
B
B
*
System
Programming
Tier 1
Menus
Demo Kit
Off/On
Clear
Memory
Exit
Programming
Ready
To Tier 2 Menus From Tier 2 Menus
#
A
B
A
B
A
B
A
B
A
B
*
#
*
#
*
#
*
#
*
A
B
A
B
A
B
A
B
#
*
#
*
#
*
#
A
B
#
*
Menus
Tier 2
Security Phones
Phone
Options
Timers
Touchpad
Options
Reporting
Siren
Options
Sensors
Accessory
Modules
Onboard
Options
