892800A7-850P.PDF
850 î P * ** * * * * * * * * * * * * * * * * * N *
850-P Feeder Protection System
(Standard: English, High Voltage Power Supply, Graphical Control Panel)
Application P | | ||||||||||||||||||| PadMount, Multi Feeder
Phase Currents - Slot J P1 | | | | | | | | | | | | | | | | | | | | 1A three-phase current inputs (J1) + 4 voltage inputs (J2)
P5 | | | | | | | | | | | | | | | | | | | | 5A three-phase current inputs (J1) + 4 voltage inputs (J2)
L1 | | | | | | | | | | | | | | | | | | | | 1A three-phase current inputs (J1) + 6 LEA inputs (J2)
L5 | | | | | | | | | | | | | | | | | | | | 5A three-phase current inputs (J1) + 6 LEA inputs (J2)
Phase Currents - Slot K R1 ||||||||||||||||||| 1A three-phase inputs (K1), 1A three-phase inputs (K2)
R5||||||||||||||||||| 5A three-phase inputs (K1), 5A three-phase inputs (K2)
Ground Currents P1 | | | | | | | | | | | | | | | | | | No Ground (with option R1 only)
P5 | | | | | | | | | | | | | | | | | | No Ground (with option R5 only)
G1 | | | | | | | | | | | | | | | | | | 1A ground input
G5 | | | | | | | | | | | | | | | | | | 5A ground input
Power Supply L | | | |||||||||||||| 24 to 48 V DC
H||||||||||||||||| 110 to 250 V DC/110 to 230 V AC
Slot B (LV I/O) N | | | | | | | | | | | | | | | | None
R | | | | | | | | | | | | | | | | 6 x RTDs (Pt100, Ni100, Ni120)
S | | | | | | | | | | | | | | | | 6 x RTDs (Pt100, Ni100, Ni120, Cu10)
C | | | | | | | | | | | | | | | | 15 Digital Inputs
Slot C (LV I/O) N | |||||||||||||| None
R||||||||||||||| 6 x RTDs (Pt100, Ni100, Ni120)
S||||||||||||||| 6 x RTDs (Pt100, Ni100, Ni120, Cu10)
C||||||||||||||| 15 Digital Inputs
Slot F (HV I/O) A | | | | | | | | | | | | | | 2 Form A (Vmon), 3 Form C, 7 Digital Inputs (Int/Ext Supply)
M | | | | | | | | | | | | | | 4 SSR (HSHB), 1 Critical Failsafe Relay, 7 Digital Inputs (Int/Ext supply)
Slot G (HV I/O) N ||||||||||||| None
A||||||||||||| 2 Form A, 3 Form C, 7 Digital Inputs (Int/Ext Supply)
B||||||||||||| 10 Digital Inputs, 9 Form A
D||||||||||||| 8 Double Pole Outputs
K||||||||||||| 10 Digital Inputs, 5 Form A, 1 Form C
L||||||||||||| 7 DcmA O/P, 4 DcmA I/P, 1 RTD
M||||||||||||| 4 SSR (HSHB), 1 Form C Relay, 7 Digital Inputs (Int/Ext supply)
Slot H (HV I/O) N | | | | | | | | | | | | None
A | | | | | | | | | | | | 2 Form A, 3 Form C, 7 Digital Inputs (Int/Ext supply)
B | | | | | | | | | | | | 10 Digital Inputs, 9 Form A
D | | | | | | | | | | | | 8 Double Pole Outputs
K | | | | | | | | | | | | 10 Digital Inputs, 5 Form A, 1 Form C
M | | | | | | | | | | | | 4 SSR (HSHB), 1 Form C Relay, 7 Digital Inputs (Int/Ext supply)
Faceplate M | | | |||||||| Basic: Membrane Keypad with 3 Pushbuttons
G||||||||||| Standard: Rugged Keypad 3 Pushbuttons
A||||||||||| Advanced: Membrane Front Panel with 10 Pushbuttons
Current Protection P
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Standard (850-P): 50P (4/CT bank), 50N (4/CT bank), 50G (4/CT bank), 51P (2/CT
bank), 51N (2/CT bank), 51G (2/CT bank), 50_2 (4/CT bank), 51_2 (2/CT bank)
Voltage Monitoring and Protection Q | |||||||| Standard (850-P): 27P (4/VT banks), 59P (4), 59N (4), 59_2 (2/VT banks)
Control
T
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Advanced HMI (850-P): Setpoint Group Control, Virtual Inputs, Trip Bus (6), Breaker
Control (2), FlexLogic, 50BF (1/CT bank), Tab PBs, Annunciator Panel, Configurable
SLDs with Bay Control
Monitoring P
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Standard (850-P): Breakers Coil Monitoring (1/Bkr), Harmonics, THD, Demand, Trip
Counters, Data Logger, Advanced Breaker Health (1/Bkr), Harmonic Detection (6)
Communications
1
1. Communications options 2A and 2E have been discontinued.
S E
|
|
|
|
|
|
|
|
|
|
Standard: Front USB, 1 x Rear RS485: Modbus RTU, DNP3.0, IEC60870-5-103 + 1 x
Ethernet (Modbus TCP, DNP)
1 E
|
|
|
|
|
|
|
|
|
|
Advanced: Front USB, 1 x Rear RS485 + 2 x Ethernet Fiber, MODBUS RTU/TCP,
DNP3.0, IEC 60870-5-103/104, 1588, SNTP, OPC-UA
1 P | | | | | Advanced + PRP
3 A | | | | | Advanced + Extended IEC 61850
3 E | | | | | Advanced + PRP + Extended IEC 61850
Advanced Communications Connector N | | | | None
S|||| ST, Multi-mode 1310 nm
C|||| RJ45, Copper 10/100 M
Wireless Communication N | | | None
W | | | WiFi 802.11
Security B| | Basic
A| | Advanced: CyberSentry Level 1
Future Option N N Not Available
