No. Description Warning Alarm/Trip Alarm/Trip Lock Parameter
Reference
17 Control word time-out (X) (X) O-04 Control Word
Timeout Function
20 Temp. Input Error
21 Param Error
23 Internal Fans X
24 External Fans X
25 Brake resistor short-circuited X
26 Brake resistor power limit (X) (X) B-13 Braking Thermal
Overload
27 Brake chopper short-circuited X X
28 Brake check (X) (X) B-15 Brake Check
29 Heatsink temp X X X
30 Motor phase U missing (X) (X) (X) H-78 Missing Motor
Phase Function
31 Motor phase V missing (X) (X) (X) H-78 Missing Motor
Phase Function
32 Motor phase W missing (X) (X) (X) H-78 Missing Motor
Phase Function
33 Inrush Fault X X
34 Network communication fault X X
35 Option Fault
36 Mains failure X X
37 Phase imbalance X
38 Internal Fault X X
39 Heatsink sensor X X
40 Overload of Digital Output Terminal 27 (X) E-00 Digital I/O Mode,
E-51 Terminal 27 Mode
41 Overload of Digital Output Terminal 29 (X) E-00 Digital I/O Mode,
E-52 Terminal 29 Mode
42 Ovrld X30/6-7 (X)
43 Ext. Supply (option)
45 Earth Fault 2 X X
46 Pwr. card supply X X
47 24 V supply low X X X
48 1.8 V supply low X X
49 Speed limit X H-36 Trip Speed Low
[RPM]
50 Auto Tune calibration failed X
51 Auto Tune check U
nom
and I
nom
X
52 Auto Tune low I
nom
X
53 Auto Tune motor too big X
54 Auto Tune motor too small X
55 Auto Tune parameter out of range X
56 Auto Tune interrupted by user X
57 Auto Tune time-out X
58 Auto Tune internal fault X X
59 Current limit X
61 Feedback Error (X) (X) H-20 Motor Feedback
Loss Function
62 Output Frequency at Maximum Limit X
64 Voltage Limit X
65 Control Board Over-temperature X X X
Warnings and Alarms
AF-600 FP
TM
Design and Installation Guide
74 DET-768b
