No. Description Warning Alarm/Trip Alarm/Trip Lock Parameter
Reference
66 Heat sink Temperature Low X
67 Option Module Configuration has Changed X
69 Pwr. Card Temp X X
70 Illegal Drive configuration X
75 Illegal Profile Sel. X
76 Power Unit Setup X
77 Reduced power mode X SP-59 Actual Number of
Inverter Units
78 Tracking Error (X) (X) H-24 Tracking Error
Function
79 Illegal PS config X X
80 Drive Restored to Factory Settings X
81 CSIV corrupt X
82 CSIV parameter error X
83 Illegal Option Combination X
88 Option Detection X
91 Analog input 54 wrong settings X S202
246 Pwr.card supply
250 New spare parts X
251 New Type Code X X
Table 10.2 Alarm/Warning Code List
(X) Dependent on parameter
1) Cannot be Auto reset via H-04 Auto-Reset (Times)
A trip is the action following an alarm. The trip coasts the
motor and is reset by pressing [Reset] or by a digital input
(parameter group E-1# [1]). The origin event that caused
an alarm cannot damage the frequency converter or cause
dangerous conditions. A trip lock is an action when an
alarm occurs, which could damage the frequency converter
or connected parts. A trip lock situation can only be reset
by a power cycling.
Warning yellow
Alarm flashing red
Trip locked yellow and red
Table 10.3 LED Indication
Bit Hex Dec Alarm Word Alarm Word 2 Warning Word Warning
Word 2
Extended
Status Word
Alarm Word Extended Status Word
0 00000001 1 Brake Check (A28) ServiceTrip,
Read/Write
Brake Check (W28) reserved Ramping
1 00000002 2 Pwr. Card Temp
(A69)
ServiceTrip,
(reserved)
Pwr. Card Temp (W69) reserved Auto Tune Running
2 00000004 4 Earth Fault (A14) ServiceTrip,
Typecode/
Sparepart
Earth Fault (W14) reserved Start CW/CCW
3 00000008 8 Ctrl.Card Temp
(A65)
ServiceTrip,
(reserved)
Ctrl.Card Temp (W65) reserved Slow Down
4 00000010 16 Ctrl. Word TO
(A17)
ServiceTrip,
(reserved)
Ctrl. Word TO (W17) Catch Up
5 00000020 32 Over Current
(A13)
reserved Over Current (W13) reserved Feedback High
6 00000040 64 Torque Limit
(A12)
reserved Torque Limit (W12) reserved Feedback Low
7 00000080 128 Motor Th Over
(A11)
reserved Motor Th Over (W11) reserved Output Current
High
Warnings and Alarms
AF-600 FP
TM
Design and Installation Guide
DET-768b 75
