GE AF-600 FP Series Design And Installation Guide

Bit Hex Dec Alarm Word Alarm Word 2 Warning Word Warning
Word 2
Extended
Status Word
8 00000100 256 Motor Electronic
OL Over (A10)
reserved Motor Electronic OL
Over (W10)
reserved Output Current Low
9 00000200 512 Drive Overld. (A9) reserved Drive Overld (W9) reserved Output Freq High
10 00000400 1024 DC under Volt
(A8)
reserved DC under Volt (W8) Output Freq Low
11 00000800 2048 DC over Volt (A7) reserved DC over Volt (W7) Brake Check OK
12 00001000 4096 Short Circuit
(A16)
reserved DC Voltage Low (W6) reserved Braking Max
13 00002000 8192 Inrush Fault (A33) reserved DC Voltage High (W5) Braking
14 00004000 16384 Mains ph. Loss
(A4)
reserved Mains ph. Loss (W4) Out of Speed Range
15 00008000 32768 Auto Tune Not
OK
reserved No Motor (W3) OVC Active
16 00010000 65536 Live Zero Error
(A2)
reserved Live Zero Error (W2) AC Brake
17 00020000 131072 Internal Fault
(A38)
KTY error 10V Low (W1) KTY Warn Password Timelock
18 00040000 262144 Brake Overload
(A26)
Fans error Brake Overload (W26) Fans Warn Password Protection
19 00080000 524288 U phase Loss
(A30)
reserved Brake Resistor (W25) reserved
20 00100000 1048576 V phase Loss
(A31)
reserved Brake IGBT (W27) reserved
21 00200000 2097152 W phase Loss
(A32)
reserved Speed Limit (W49) reserved
22 00400000 4194304 Network Fault
(A34)
reserved Network Fault (W34) reserved Unused
23 00800000 8388608 24 V Supply Low
(A47)
reserved 24V Supply Low (W47) reserved Unused
24 01000000 16777216 Mains Failure
(A36)
reserved Mains Failure (W36) reserved Unused
25 02000000 33554432 1.8V Supply Low
(A48)
reserved Current Limit (W59) reserved Unused
26 04000000 67108864 Brake Resistor
(A25)
reserved Low Temp (W66) reserved Unused
27 08000000 134217728 Brake IGBT (A27) reserved Voltage Limit (W64) reserved Unused
28 10000000 268435456 Option Change
(A67)
reserved Encoder loss (W90) reserved Unused
29 20000000 536870912 Drive Restored to
factory
settings(A80)
Feedback Fault
(A61, A90)
Feedback Fault (W61,
W90)
Unused
30 40000000 1073741824 Safe Stop (A68) Safe Stop (A71) Safe Stop (W68) Safe Stop
(W71)
Unused
31 80000000 2147483648 Mech. brake low
(A63)
Dangerous
Failure (A72)
Extended Status Word Unused
Table 10.4 Description of Alarm Word, Warning Word and Extended Status Word
The alarm words, warning words and extended status words can be read out via serial bus or optional network for
diagnostics. See also DR-94 Ext. Status Word.
Warnings and Alarms
AF-600 FP
TM
Design and Installation Guide
76 DET-768b
