3.1.10 Remote Mounting Kit for keypad
The keypad can be moved to the front of a cabinet by using the remote build
in kit. The Unit Size is the IP65. The fastening screws must be tightened with
a torque of max. 1 Nm.
Technical data
Unit Size: IP 65 front
Max. cable length between and unit: 3 m
Communication std: RS 485
Ordering no. RMKYDAC
Illustration 3.5: keypad Kit with graphical keypad, fasteners, 3 m cable and gasket.
