4.2 Electrical Installation
4.2.1 Cables General
NB!
For the AF-600 FP drives above 125HP, please see AF-600 FP High Power Operating Instructions .
NB!
Cables General
Always comply with national and local regulations on cable cross-sections.
Details of terminal tightening torques.
Power (kW) Torque (Nm)
Unit
200-240
V
380-480
V
525-600
V
Mains Motor
DC connec-
tion
Brake Earth Relay
12 0.75 - 2.2 0.75 - 4.0 0.75 - 4.0 1.8 1.8 1.8 1.8 3 0.6
13 3.7 5.5 - 7.5 5.5 - 7.5 1.8 1.8 1.8 1.8 3 0.6
15 0.75 - 3.7 0.75 - 7.5 0.75 - 7.5 1.8 1.8 1.8 1.8 3 0.6
21 5.5 - 11 11 - 18.5 - 1.8 1.8 1.5 1.5 3 0.6
22
-
15
22
30
-
-
4.5
4.5
2)
4.5
4.5
2)
3.7
3.7
3.7
3.7
3
3
0.6
0.6
23 5.5 - 11 11 - 18.5 11 - 18.5 1.8 1.8 1.8 1.8 3 0.6
24 11 - 18.5 18.5 - 37 18.5 - 37 4.5 4.5 4.5 4.5 3 0.6
31 18.5 - 30 37 - 55 - 10 10 10 10 3 0.6
32 37 - 45 75 - 90
-
-
14/24
1)
14/24
1)
14 14 3 0.6
33 18.5 - 30 37 - 55 37 - 55 10 10 10 10 3 0.6
34 30 - 45 55 - 90 55 - 90
14/24
1)
14/24
1)
14 14 3 0.6
High Power
Unit
380-480
V
525-690
V
Mains Motor
DC connec-
tion
Brake Earth Relay
41/43 110-132 45-160 19 19 9.6 9.6 19 0.6
42/44 160-250 200-400 19 19 9.6 9.6 19 0.6
51/52 315-450 450-630 19 19 19 9.6 19 0.6
61-63
3)
500-710
710-900 19 19 19 9.6 19 0.6
62-64
3)
800-1000
1000-1400 19 19 19 9.6 19 0.6
Table 4.2: Tightening of terminals
1) For different cable dimensions x/y, where x ≤ 95 mm² and y ≥ 95 mm²
2) Cable dimensions above 18.5 kW ≥ 35 mm
2
and below 22 kW ≤ 10 mm
2
3) For data on the 6x frame size please consult AF-600 FP High Power Operating Instructions
