12 13 15 21 22 23 24 31 32 33 34
130BA810.10
IP20/21* IP20/21* IP55/66 IP21/55/66 IP21/55/66 IP20/21* IP20/21* IP21/55/66 IP21/55/66 IP20/21* IP20/21*
Illustration 4.1: Top and bottom mounting holes.
Illustration 4.2: Top and bottom mounting holes. (24+33+34 only)
Accessory bags containing necessary brackets, screws and connectors are included with the drives upon delivery.
All measurements in mm.
* IP21 can be established with a kit as described in the section: IP 21/ IP 4X/ TYPE 1 Enclosure Kit in the Design Guide.
4.1.1 Mechanical Front Views
AF-600 FP Design Guide
58
4
