GE af-600 fp

AF-600 FP Bussmann PN* Rating Siba Internal Bussmann Option
750 HP 170M7081 1600 A, 700 V 20 695 32.1600 170M7082
950 HP 170M7081 1600 A, 700 V 20 695 32.1600 170M7082
1050 HP 170M7081 1600 A, 700 V 20 695 32.1600 170M7082
1150 HP 170M7081 1600 A, 700 V 20 695 32.1600 170M7082
1350 HP 170M7082 2000 A, 700 V 20 695 32.2000 170M7082
Table 4.12: Unit Sizes 61, 62, 63, and 64, 525-690 V
AF-600 FP
Bussmann PN* Rating Siba
750 HP 170M8611 1100 A, 1000 V 20 781 32. 1000
950 HP 170M8611 1100 A, 1000 V 20 781 32. 1000
1050 HP 170M8611 1100 A, 1000 V 20 781 32. 1000
1150 HP 170M8611 1100 A, 1000 V 20 781 32. 1000
Table 4.13: Unit Sizes 61, 62, 63, and 64, Inverter module DC Link 525-690 V
*170M fuses from Bussmann shown use the -/80 visual indicator, -TN/80 Type T, -/110 or TN/110 Type T indicator fuses of the same size and amperage may be
substituted for external use.
Supplementary fuses
Unit Sizes Bussmann PN* Rating
4X, 5X and 6X KTK-4 4 A, 600 V
Table 4.14: SMPS Fuse
Size/Type
Bussmann PN* LittelFuse Rating
150HP-450HP, 380-480 V KTK-4 4 A, 600 V
125HP-500HP, 525-690 V KTK-4 4 A, 600 V
500HP-1350HP, 380-480 V KLK-15 15A, 600 V
600HP-1350HP, 525-690 V KLK-15 15A, 600 V
Table 4.15: Fan Fuses
Size/Type
Bussmann PN* Rating Alternative Fuses
650HP-1350HP, 380-480 V 2.5-4.0 A LPJ-6 SP or SPI 6 A, 600 V Any listed Class J Dual Element,
Time Delay, 6A
750HP-1350HP, 525-690 V LPJ-10 SP or SPI 10 A, 600 V Any listed Class J Dual Element,
Time Delay, 10 A
650HP-1350HP, 380-480 V 4.0-6.3 A LPJ-10 SP or SPI 10 A, 600 V Any listed Class J Dual Element,
Time Delay, 10 A
750HP-1350HP, 525-690 V LPJ-15 SP or SPI 15 A, 600 V Any listed Class J Dual Element,
Time Delay, 15 A
650HP-1350HP, 380-480 V 6.3 - 10 A LPJ-15 SP or SPI 15 A, 600 V Any listed Class J Dual Element,
Time Delay, 15 A
750HP-1350HP, 525-690 V LPJ-20 SP or SPI 20 A, 600 V Any listed Class J Dual Element,
Time Delay, 20A
650HP-1350HP, 380-480 V 10 - 16 A LPJ-25 SP or SPI 25 A, 600 V Any listed Class J Dual Element,
Time Delay, 25 A
750HP-1350HP, 525-690 V LPJ-20 SP or SPI 20 A, 600 V Any listed Class J Dual Element,
Time Delay, 20 A
Table 4.16: Manual Motor Controller Fuses
Unit Sizes
Bussmann PN* Rating Alternative Fuses
6X LPJ-30 SP or SPI 30 A, 600 V Any listed Class J Dual Element, Time
Delay, 30 A
Table 4.17: 30 A Fuse Protected Terminal Fuse
Unit Sizes
Bussmann PN* Rating Alternative Fuses
6X LPJ-6 SP or SPI 6 A, 600 V Any listed Class J Dual Element, Time
Delay, 6 A
Table 4.18: Control Transformer Fuse
AF-600 FP Design Guide
