GE AF-650 GP - Dimensions, Unit Size 6 X

13.1.7 Dimensions, Unit Size 6x
Figure 13.18 Unit Size 61 (Floor Mount)
Min. 200 (7.9)
Air Space Outlet
607
(23.9)
1804
(71.0)
IP 21/NEMA 1
2100 m
3
/hr
(1236 CFM)
2280
(89.8)
2205
(86.8)
1497
(58.9)
3941 m
3
/hr
(2320 CFM)
IP 54/NEMA 12
1575 m
3
/hr
(927 CFM)
130BD082.10
Figure 13.19 Unit Size 62 (Floor Mount)
Specifications
AF-650 GP
TM
Design and Installation Guide
13-12 DET-767A
133
