GE AF-650 GP - Fuse Tables

13.3.4 Fuse Tables
AF-650 GP 3-phase Recommended fuse size Recommended max fuse
[kW]/[HP]
0.25/1/3
gG-16 gG-25
0.37/1/2
0.75/1
1.5/2
2.2/3
3.7/5 gG-20 gG-32
5.5/7.5 gG-50 gG-63
7.5/10
gG-80 gG-12511/15
15/20
18.5/25 gG-125 gG-150
22/30 aR-160 aR-160
30/40 aR-200 aR-200
37/50 aR-250 aR-250
Table 13.5 200–240 V, IP20/Open Chassis
AF-650 GP 3-phase Recommended fuse size Recommended max fuse
[kW]/[HP]
0.25/1/3
gG-20 gG-32
0.37/1/2
0.75/1
1.5/2
2.2/3
3.7/5
5.5/7.5
gG-63 gG-80
7.5/10
11/15 gG-80 gG-100
15/20
gG-125 gG-160
18.5/25
22/30 aR-160 aR-160
30/40 aR-200 aR-200
37/50 aR-250 aR-250
Table 13.6 200–240 V, IP55/Nema 12 and IP66/Nema 4X
