GE AF-650 GP

Environment
Enclosure IP20 Open Chassis, Nema 1 with field-installed kit, Nema 12, and Nema 4X
Vibration test 1.0 g (75 kW/100 HP and below)/0.7 g (above 75 kW/100 HP)
Max. relative humidity 5%–93% (IEC 721-3-3; Class 3K3 (non-condensing) during operation
Aggressive environment (IEC 60068-2-43) H
2
S test
class Kd
Ambient temperature Max. 122° F [50°C]
Minimum ambient temperature during full-scale operation 32° F [0°C]
Minimum ambient temperature at reduced performance 14° F [-10°C]
Temperature during storage/transport -13°–+149°/158° F [-25° to +65°/70°°C]
Maximum altitude above sea level without derating 3,300 ft [1,000 m]
Derating for high altitude, see 7.5 Derating.
EMC standards, Emission EN 61800-3, EN 61000-6-3/4, EN 55011
EMC standards, Immunity
EN 61800-3, EN 61000-6-1/2,
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6
See section on special conditions in 7.2 Immunity Requirements..
