For basic serial communication set-up, select the following
1. Protocol type in O-30 Protocol.
2. Adjustable frequency drive address in
O-31 Address.
3. Baud rate in O-32 Drive Port Baud Rate.
•
Two communication protocols are internal to the
adjustable frequency drive.
Drive profile
Modbus RTU
•
Functions can be programmed remotely using
the protocol software and RS-485 connection or
in parameter group O-## Options / Comms
•
Selecting a specific communication protocol
changes various default parameter settings to
match that protocol’s specifications along with
making additional protocol-specific parameters
available.
•
Option cards which can be installed in the
adjustable frequency drive are available to
provide additional communication protocols. See
the option-card documentation for installation
and operation instructions
Installation
AF-650 GP
TM
Design and Installation Guide
DET-767A 2-15
2
