– 28 –
Main Board
J29 INDOOR
THERMISTORS
J30 OUTDOOR
J2 INDOOR
MOTORS
J3 OUTDOOR
HEATER PLUG
J4 LOW VOLTAGE
TRANSFORMER
J21 COMPRESSOR
DLB RELAY
J23 ICR PUMP
J22 REVERSING
VALVE COIL
AC INPUT PLUG
