GE AZ45E07DA Series - Fan Cycle - Resistance Heating Mode

– 15 –
The indoor fan and heaters are turned On at the same time. The indoor fan is turned OȺ, approximately 20
seconds after the heaters are de-energized as shown. In the oȺ mode, the indoor fan will continue to operate
for six seconds after the user has stopped the Zoneline, in order to dissipate the heat inside the Zoneline.
In the heating mode, the indoor fan is designed to operate at two diȺerent speeds (RPM).
FAN CYCLE - RESISTANCE HEATING MODE
Fan Cycle - Resistance Heating Mode
Temperature
Temperature Setting
-1.8°F
Heater
INDOOR FAN
ON
20 sec
ON
ON
