Chapter 3: Components and User Controls

Component/Control Function

7. Air Filter – For proper cooling it is important to keep

the air lter clear of obstruction. See the maintenance

section of this manual for more details.

8. Power Cord Receptacle

9. Fuse Cover - Houses two power inlet fuses

10. Mounting Bracket Holes – Four holes on the bottom

of the main unit are used to attach the optional

mounting bracket. The mounting bracket can be

positioned on the left or right side of the light box.

BiliSoft Fiberoptic Light Pad Assembly

The beroptic light pad comes in two sizes – large and small. The LED light source in the BiliSoft light box is

focused on the beroptic lenses at the end of the beroptic cable connector. The beroptic cable contains

plastic bers that transmit light from the light box to the light pad. The light pad is constructed of these plastic

bers woven into a mat. This patented process produces a light pad that emits light over its entire surface.

Average light intensity depends on the size of the light pad. See Specications section for more details.

Component/Control

1. Fiberoptic light pad

2. Fiberoptic cable connector

3. Fiberoptic lenses

4. Fiberoptic cable
