GE Corometrics 172 Service Manual

6-2 170 Series Monitor Revision C
2000947-004
Functional Checkout Procedure: Equipment Required
Equipment Required
Table 6-1 provides a complete listing of equipment required for a functional
checkout procedure.
Table 6-1. Equipment Required
Test Equipment
FECG
 Model 325 Simulator (14203A/B)
 Monitor Interconnect Cable (14212A/B)
Legplate
 Legplate for Qwik Connect Plus with round connector
(1590AAO)
US/FMD
 Model 325 Simulator (14203A/B)
 Monitor Interconnect Cable (14212A/B)
US Transducer
 Nautilus Ultrasound Transducer
(5700GAX–5700MAX Series)
TOCO/IUP
 Model 325 Simulator (14203A/B)
 Monitor Interconnect Cable (14212A/B)
Tocotransducer
 Nautilus Tocotransducer
(2264GAX–2264MAX Series)
Strain Gauge Transducer
 Reusable Strain Gauge with holder (4007BAX); or
 Reusable Strain Gauge without holder (4007LAX); or
 Disposable Strain Gauge (4009AAX)
NOTE: These items are no longer sold by GE. However,
transducers in the field are compatible with the 170
Series Monitor.
Pattern Memory
 Model 325 Simulator (14203A/B)
 Monitor Interconnect Cable (14212A/B)
Dual Heart Rate (FECG/US)
 Model 325 Simulator (14203A/B)
 Monitor Interconnect Cable (14212A/B)
Dual Heart Rate (US/US2)
 Two Model 325 Simulators (14203A/B) with two sets
of Monitor Interconnect Cables (14212A/B); or
 Two Nautilus Ultrasound Transducers
5700GAX–5700MAX Series)
Alarms
 Model 325 Simulator (14203A/B)
 Monitor Interconnect Cable (14212A/B)
