Field replaceable units: Field replaceable units
7-4 Dash 3000/4000/5000 2000966-542D
2026653-007 See “Replace display assembly parts” on page 7-26 for
disassembly.
DASH 3K DISPLAY ASSEMBLY WITHOUT LCD
 Includes display components and labels for Dash
3000 patient monitor. (no LCD)
X
Display flex assembly - See “Replace display flex assembly” on page 7-24 for disassembly.
2013114-026 DASH 4K/5K DISPLAY FLEX
 Includes complete display flex for Dash 4000/5000
patient monitors.
XX
Alarm light assemblies - See “Replace display assembly parts” on page 7-26 for disassembly.
2026653-025 DASH 4K ALARM LIGHT ASSEMBLY
 Includes alarm light, cable, lens and lens blank for
10” Dash 4000 patient monitor.
X
2026653-026 DASH 5K ALARM LIGHT ASSEMBLY
 Includes alarm light, cable, lens and lens blank for
12” Dash 5000 patient monitor.
X
Inverter assemblies - See “Replace display assembly parts” on page 7-26 for disassembly.
2026653-022 DASH 3K DISPLAY INVERTER
 Includes display inverter and cable for Dash 3000
patient monitor.
X
2026653-023 DASH 4K DISPLAY INVERTER
 Includes inverter.
 Contains a back plate that has a clearance hole to
accommodate the height of the capacitors on the
inverter.
X
2026653-034 DASH 5K DISPLAY INVERTER
 Includes inverter.
X
Keypad or Trim Knob assemblies - See “Replace display assembly parts” on page 7-26 for
disassembly.
2026653-016 DASH 3K KEYPAD ASSEMBLY
 Includes keypad assembly with encoder and
hardware for Dash 3000 patient monitor.
X
2026653-017 DASH 4K KEYPAD ASSEMBLY
 Includes keypad assembly with encoder and
hardware for Dash 4000 patient monitor.
X
2026653-018 DASH 5K KEYPAD ASSEMBLY
 Includes keypad assembly with encoder and
hardware for Dash 5000 patient monitor.
X
2026653-024 DASH3K/4K/5K TRIM KNOB
 Includes Trim Knobs and clip.
XXX
Part number Description
Dash
3000
Dash
4000
Dash
5000
