Field replaceable units: Replace main unit parts
2000966-542D Dash 3000/4000/5000 7-45
b. Remove the wireless card from the PC card bracket by pressing
the CF card eject button. To press the CF card eject button,
carefully insert the flat end of a pen approximately 1- inch deep
and push the CF flash card eject button as shown.
c. Carefully disconnect the antennas using a pen tip, small
screwdriver, or needle nose pliers.
d. Place the wireless card in a safe place.
4. Remove the DAS assembly according to steps starting on page 7-37.
973A
974A
CF card eject button
