OPM_SGS_ISG_10K_40K_0US_V010.doc 32/45 Installation Guide SG Series 10, 20, 30 & 40 kVA
Notices for installation
X1
SGT5000_030-040_UPS BR1-2-3_01
OFF
ON
OFF
ON
X2
BR1 BR2
BR3
Fig. 3.8.5-2 Interconnection links BR1, BR2 and BR3 of SG Series 30 and 40 kVA
For separate Bypass and Rectifier Input configuration, the interconnection links BR1, BR2 and
BR3 must be removed.
