C: Electrical Design
C-4.
Overview: DIP Switch and Jumper Settings
Figure C-13: Overview: DIP Switch and Jumper Settings
red: current DIP
switch position
DIP Switch Positions on PCB IF for eBike
eBike Basic
eBike Comfort
eBike L/EL
without BP
without BP
without BP
eBike Basic
eBike Comfort
eBike L/EL
with BP
with BP
with BP
53
55
