Chapter 5: Diagnostics, maintenance, and testing
EST iO64 and iO500 Technical Reference Manual 199
To capture a report:
1. On the Transfer menu, click Capture Text.
2. In the File box in the Capture Text dialog box, type a name for
the captured text file. Example: History Report. The TXT file
extension is added automatically.
If you want to save the file somewhere other than the default
location, click the Browse button, navigate to the desired
location, then name the file.
3. Click Start.
4. On the front panel, go to the main menu, choose Reports, then
choose the report you want captured.
5. On the Print Output menu, choose Printer to send the report to
HyperTerminal.
6. Wait until the report transfer is complete.
7. On the Transfer menu, click Capture Text, and then Stop.
