Zone settings worksheet
The zone settings worksheet is used to document the configuration
and settings for each of the zones on your system.
Note: Print a copy of this worksheet for each zone in your system.
Note: For default settings, refer to “Factory default settings.”
Type ☐ Alarm ☐ Waterflow
☐ Supervisory
(latching)
☐ Supervisory
(nonlatching)
☐ Monitor
Label (up to 40 characters)
Correlation groups
Device allocation:
First address (no less than the last address of the previous zone + 1)
Last address (first address + the number of devices – 1)
Event notification:
Active
Print ☐ Yes ☐ No
NET ☐ Yes ☐ No
Dialer ☐ Acct 1 ☐ Acct 1 & 2 ☐ Acct 2 ☐ None
Code (4-digit coded output)
CID
Trouble
Print ☐ Yes ☐ No
NET ☐ Yes ☐ No
Dialer ☐ Acct 1 ☐ Acct 1 & 2 ☐ Acct 2 ☐ None
Code (4-digit coded output)
CID
Disable
Print ☐ Yes ☐ No
NET ☐ Yes ☐ No
Dialer ☐ Acct 1 ☐ Acct 1 & 2 ☐ Acct 2 ☐ None
Code (4-digit coded output)
CID
Pre alarm
Print ☐ Yes ☐ No
NET ☐ Yes ☐ No
Dialer ☐ Acct 1 ☐ Acct 1 & 2 ☐ Acct 2 ☐ None
Code (4-digit coded output)
CID
