Appendix C: Front panel menu flowcharts
EST iO64 and iO500 Technical Reference Manual 237
Control menu
Control
Device
Zone
Panel Event
Panel NAC
Enable/Disable
Device
Panel NAC
Activate/Restore
Drill
Enable/Disable
Activate/Restore
Control
Device Enable<>
001
Device 001
Zone Enable<>
01
Zone 01
Device Activate<>
001
Device 001
Loop 01<>
Device
Loop 01<>
Device
Continue?
Cancel?
Warning Device Active
Panel Event Enable<>
300
Event 300
1
NAC 1
Panel NAC Enable<>
1
NAC 1
Panel NAC Activate<>
Loop Event Enable<>
001
Event 001
Loop Event
Continue?
Cancel?
Warning Device Active
