GE EST iO500

Appendix C: Front panel menu flowcharts
242 EST iO64 and iO500 Technical Reference Manual
Advanced: Device configuration menu
Label
aaaaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaaaa
<-Save <-Back
Adv
Device
Config
Loop 01<>
Device
Device
Number 001
Device 001
Group 01 Yes<>
Correlation Groups
Group 02 Yes<>
Group 03 Yes<>
...
Group 32 Yes<>
Save
Printer Yes<>
Dialer Account1&2<>
CODER 10-10-10-10
Notification
CID 110
NET Yes<>
Save
Active
Trouble
Disable
Test
Event Notification
Pre Alarm
Maint. Alert
Alarm Verify
Label >
Zone 01<>
Correlation Groups
Event Notification
Device
Day Sens Normal<>
Save
Type Smoke<>
Follow Alarm<>
Day PreAlarm% 50 <>
Night Sens Normal<>
Night PreAlarm% 50 <>
Base Type Standard<>
