Appendix C: Front panel menu flowcharts
EST iO64 and iO500 Technical Reference Manual 247
Advanced: Loop events menu
Loop 2 Fault
Loop 2 Map Fault
Loop 2 Card Fault
Loop 2 Unconf Alarm
Loop 2 Unconf Trbl
Adv
Loop
Events
Loop 1 Initializing
Loop 1 Fault
Loop 1 Map Fault
Loop Events
Loop 1 Card Fault
Loop 1 Unconf Alarm
Loop 1 Unconf Trbl
Loop 2 Initializing
Loop 1 Map Mismatch
Loop 1 Over Limits
Loop 1 Device Zero
Loop 1 Mapping
Loop 2 Map Mismatch
Loop 2 Over Limits
Loop 2 Devic Zero
Loop 2 Mapping
Event Notification
Event Name xxxxxxxxxx
Trouble
Printer Yes<>
Dialer Account1&2<>
CID 110
NET Yes<>
Save
