Chapter 3: Programming
EST iO64 and iO500 Technical Reference Manual 111
Loop 1 Device 001
Label goes here
Label continued
<Save <Back
Label your devices:
1. Next to "Device," select the device (number) that you want to
label.
2. Enter a text label for the device (up to 40 characters and two
lines). The default label is "Loop X Device XXX."
3. Press Enter to save the label and go to the next device (number).
Note: Pressing the Enter button saves the current label and
then goes to the next available device so that you can quickly
go to each device and label it.
4. Enter a text label for the device (up to 40 characters and two
lines).
5. Repeat steps 3 and 4 until all devices are labeled.
6. When you are finished labeling, make sure the cursor is on the
device number field, and press the Cancel button to exit and go
to the next auto programming option.
Zone 01>
Label goes here
Label continued
<Save <Back
Label your zones:
1. Next to "Zone," select the zone (number) that you want to label.
2. Enter a text label for the zone (up to 40 characters and two
lines). The default label is "Zone XX."
3. Press Enter to save the label and go to the next zone (number).
Note: Pressing the Enter button saves the current label and
then goes to the next zone number so that you can quickly go
to each zone and label it.
4. Enter a text label for the zone (up to 40 characters and two
lines).
5. Repeat steps 3 and 4 until all zones are labeled.
6. When you are finished labeling, make sure the cursor is on the
zone number, and press the Cancel button to exit and go to the
next auto programming option.
