Appendix D: Applications
EST iO64 and iO500 Technical Reference Manual 255
Wiring
12345678
RM1
SIG+ SIG- DATA- OUT DATA- IN DATA+ IN/OUT SIG+ SIG- DATA- OUT DATA- IN DATA+ IN/OUT
N.C.
JP1: 24 VDC Monitor
24 VDC+
24 VDC-
A
UX RISE
R
DATA+
DATA-
SLC
DATA+
DATA-
SLC
FIRST
DETECTOR
LAST
DETECTOR
RED
WHT
7
8
12
3
4
6
CT1
SLC
DATA+
DATA-
DATA+
DATA-
24 VDC+
24 VDC-
SLC
PAM-1
47 k
EOLR
Ω
AUX RISER
A
LTERNATE RISER SUPERVISION CIRCUIT
Double screw
terminal block
(supplied by installer)
BLU
ORG
Programming
1. Set the panel’s Event Notification option for Device
2. Configure the smoke detectors as follows:
Device Type: Smoke or Smoke Heat depending on the detectors
used
Message Line 1: SMOKE_<N>, where <N> can be the device
address or other number
Message Line 2: As required
Coder: 0-0-0-0
Sensitivity: As required
Alt Sensitivity: As required
Pre Alarm: Any value other than None
