Figure 37. Partially close the door as shown
Figure 38. Adjust the pilot device bracket and extension bubble lip
so it enters in between the keeper bracket and inside of the door
Figure 39. Close the door completely and turn the 1/4-turn latches
1/4 Turn Latch
Extension Bubble
Door Door Cut Out
Gasket
Locking Bracket
