Evolution Series E9000 User Manual
28
Renewal Parts
Because of the variety of components furnished in the
E9000 motor control center, the suggested spare parts
will vary. You should consider maintaining an adequate
supply of the following components as spares:
• Overload heaters
• Power and control circuit fuses
• Replacement starter contact kits
• Starter coils
• Pilot lights
• Push buttons
• Circuit breakers and fusible switches
• Extra draw-out terminal blocks
• Complete starters and/or spare units as warranted
by installation needs.
Your GE account manager will be glad to assist you in
preparing a recommended parts list for your installation.
Ordering Additional or Replacement Parts
The following information is needed for supplying the
proper equipment:
1. All data on the motor control center master nameplate
2. If the unit is to be a duplicate of an existing unit, all
data on that unit’s nameplate, located on the right
side of the unit
3. NEMA control center class: I or II
4. NEMA wiring type: A, B or C
5. NEMA enclosure type: 1, 1 Gasketed, 1-HG (heavy
gasketed) 2, 3R or 12
6. Power supply characteristics:
• Voltage
• Number of phases
• Frequency in Hz
7. Control power voltage and frequency in Hz
8. Nameplate designation and title
9. Motor characteristics:
• Horsepower rating
• Speed in RPM
• Temperature rise in °C
• Full-load current in amperes
• Accelerating time in seconds
• Service factor
10. Disconnect characteristics:
• Fusible switch rating (A), fuse type, and clips
• Circuit breaker frame size and current rating (A)
11. NEMA starter size: 1, 2, 3, 4, 5, 6 or 7
12. Starter type: FVNR, FVR, RVNR, 2-speed winding
and accessories:
• Push buttons: start-stop, forward, reverse, up, down
• Transfer switch: H-O-A
• Pilot lights: quantity, color and type
• Interlocks: quantity of NO and NC
• Control power transformer
13. Unit X height or space available
14. Are horizontal shelves or other parts required?
15 Circuitry
16. All other modications
Other Information
For other information, refer to the nearest GE sales oce
and give full details, including equipment nameplate data.
Nameplates are prominently displayed on the motor
control center lineup and contain such details as service,
voltage, frequency, factory order number. Similar name-
plates are mounted on each motor control center unit.
