– 9 –
Tools Needed
(OHFWULFDO6SHFL¿FDWLRQV
AC Voltage
• Circulation Pump: 120 VAC, .8 amp – 3.8 LRA, 8GPM @ 5PSI
• Drain Pump: 120 VAC, 27 ohms, .65 amp, ~70 second cycle
•
• Tub TCO: 120 VAC, 210°F +/- 10°F Manual Reset
• Main Control: Input 120 VAC, Output 120 VAC, and Output 5 & 13.5 VDC
DC Voltage
• Door Switch: 13.5 VDC
• Water Valve: 13.5 VDC, 32 ohms, .83 GPM, ~1 minute cycle time
• UI Control: 13.5 VDC (some models have 13.5 VDC output to detergent module)
• Detergent Cup: 13.5 VDC, 25 ohms, .5 second to release detergent cup, 15 seconds to release rinse aid
• Turbidity Sensor: 5 VDC to LED, 10K ohms
• Flood Switch: 13.5 VDC, .42 amp
•
1/4” & 5/16” nut driver
R2 Quadrex bit
#15 and #20 Torx bits
#2 Phillips head screw driver
Two 5/32” Allen wrench’s (or similar size tool, see the
Door Removal section in this guide)
Adjustable wrench
Two pocket type screwdrivers
Pliers and needle nose pliers
Volt / Ohm meter (AC, DC, and ohms) with “Needle”
Type Probes
Optional: Clear door (Part #: WX05X20002)
Heater 120 VAC
Wet Dry
Watts 793 625 +/- 5%
Ohms 16.4 23.2 +/- 5%
Amps 6.6 5.2 +/- 5%
7KHUPLVWRU6SHFL¿FDWLRQV
LQÀRRGVZLWFK
Resistance Temperature
20k 50°F
11k 75°F
5.8k 100°F
3.4k 125°F
2.1k 150°F
1.3k 175°F
