GE GL 310 F3/4031 P/VR User Manual

INSTALLATION
22 OI 248 (EN) REV6 /REV5
Checklist for Installation and Commissioning
Circuit Breaker Data
Type & Serial No.:
Customer:
Station:
Installation
No. Operation to Be Performed Section
1 Safety instructions have been carefully read and are under-
stood
2.1
2 Materials provided by station checked for completeness A2
3 Shipment checked for completeness and lack of damage 6.4
4SF
6
shipping pressure in each pole column checked 6.4.2
5 Component serial numbers checked for agreement 6.6
6 Base frame and supports aligned 6.6
7 Base frame connected to supports 6.6
8 Supports tightened to final torque 6.6
9 Pole columns installed 6.8
10 Pole column B aligned and connected 6.10
11 Operating mechanisms and pole columns connected 6.10.2
12 Transport lock removed from operating mechanisms 6.7.1
13 High voltage terminal pads mounted 6.11
14 Base frame and supports earthed (grounded) 6.13
