Bulk Dispenser Tanks
Removal
Consumer
Fill
Top
Bulk Tanks
Tank Can be Removed From the Bottom Front by:
1- Leaning the Washer Back using Prop Blocks or laying the
washer on it’s side.
Bottom View
NOTE: Plug tank flange
hole to prevent spillage
Hose Clamp and
Tank Flange
3- Remove the hose clamp using same
procedure as the water valve at the bottom of
bulk tank.
2- Pull Tank out from the Bottom by lifting tank
up and off of the bottom apron lip.
To Next Page
