GE GTWN8250DWS User Manual

R-20
R-20
R-20
R-20
Diagnostics From The Board
Mode Shifter Position Switch
From the J501 connecter, check for
continuity between the GREEN and GRAY
wires. When the washer has stopped or is in
the spin cycle, the Position switch will be in the
normally open state.
When the washer is in the agitate mode the
switch will be closed.
90
